Description

Advanced Video Balancing Technology

The Mondolfo Ferro MT3650UP represents the pinnacle of digital wheel balancing, offering a sophisticated video interface that guides the operator through every step of the process. Equipped with a high-resolution widescreen monitor, the software provides intuitive 3D graphics that simplify complex balancing tasks. Whether you are balancing standard alloy wheels or high-performance racing rims, this machine ensures a professional finish every time.

Precision Positioning with Laser Line System

Accuracy is paramount in a busy workshop. The MT3650UP features an integrated LED spotlight to illuminate the work area and a Laser Line System that clearly indicates the 6 o'clock position for adhesive weight application. Combined with the AUTOSELECT function—which automatically detects wheel diameter and distance—this machine eliminates operator error and significantly reduces cycle times to just 7 seconds.

Intelligent Software for Maximum Efficiency

Beyond standard balancing, the MT3650UP includes a suite of advanced software programs designed to save time and materials. The Minimum Weight software reduces the amount of counterweights needed, while the OPT FLASH program identifies the ideal assembly position between the tyre and rim to minimize overall imbalance. For aesthetic perfection, the Hidden Weight program allows you to split weights behind the spokes of alloy rims.

Heavy-Duty Engineering for Intensive Workloads

Constructed with a reinforced chassis and a high-performance spin unit, the MT3650UP is built for industrial-grade longevity. The "zero-maintenance" motor is designed to handle high work loads without degradation in performance. Its ergonomic design features a spacious, high-resistance weight tray and a side accessory compartment to keep your universal flanges and cones organized and accessible.

Key Product Features

• Widescreen Display: High-resolution monitor for clear, intuitive graphics and software navigation.
• Laser Line System: Precision laser pointer at the 6 o'clock position for rapid weight application.
• 7-Second Cycle Time: High-speed spin and automatic braking for maximum workshop throughput.
• AUTOSELECT Function: Automatic electronic input of wheel diameter and distance.
• EASY WIDTH Calculation: Automatically predicts wheel width even without an external sonar sensor.
• Heavy-Duty Capacity: Supports wheels up to 85 kg and diameters up to 44 inches.

Technical Specifications

Frequently Asked Questions

What is the benefit of the Video interface over a standard LED display?

The video interface on the MT3650UP provides high-resolution 3D graphics that make it much easier to visualize weight placement and navigate advanced programs like OPT FLASH or Hidden Weight, reducing the learning curve for new operators.

Does the MT3650UP include a laser pointer?

Yes, it features the Laser Line System which points exactly where to place adhesive weights at the 6 o'clock position, ensuring 100% accuracy and eliminating guesswork.

Can I balance large van or 4x4 wheels on this machine?

Absolutely. With a maximum wheel weight capacity of 85kg and a heavy-duty spin unit, it is perfectly suited for everything from small passenger cars to large commercial vans and SUVs.

How does the "Minimum Weight" software help my business?

The Minimum Weight software calculates the most efficient way to balance a wheel using the least amount of lead or zinc weights possible. Over a high volume of tyres, this results in significant cost savings for your workshop.
